Cores, cavities, inserts, sliders and lifters ground to 0.005mm and hardened to 48 to 54 HRC.

Send your 2D and 3D drawings and we make the custom cores, cavities, inserts, sliders, lifters and other mold components you need, whether you are building a new mold, repairing a running tool or replacing a worn part on the shop floor.

Before anything is cut we check your critical fits, mating surfaces, forming features, steel grade, hardness and surface requirements against the approved drawing, so the component is built around the job it does in your mold instead of being treated as a general machined part.

Chat With Kim
2D And 3D Drawing Based Manufacturing New And Replacement Components Inspection To Drawing Requirements
Precision ground injection mold cores, cavities and slide inserts after machining

Tolerance

±0.005mm

Hardness

48 to 54 HRC

Quote

24 h

02Mold Components

Injection Mold Components We Manufacture

From forming inserts to moving and wear components, we make custom mold parts from your 2D drawings and 3D models. Steel grade, hardness, critical tolerances, mating dimensions and surface requirements are produced to the approved specification, not to our own assumptions.

Precision machined core and cavity inserts for an injection mold

Core And Cavity Inserts

Precision machined inserts for the surfaces that form your part. Critical profiles, shutoff areas, parting surfaces and fitting dimensions are held to what your drawing calls out.

Custom mold inserts for replaceable forming sections

Mold Inserts

Inserts for local forming features, replaceable sections, ribs, bosses and other mold details. Built either for a new tool or as a drop in for a worn or damaged section.

Injection mold slider components for side actions

Sliders

Slider components for side actions and undercut features. Sliding surfaces, shutoff geometry, wear areas and mating dimensions are matched to the mold structure you are running.

Mold lifters for internal undercuts and ejection movement

Lifters

Lifters and related components for internal undercuts and ejection movement. Angle, working surfaces, fit dimensions and contact areas follow the approved design.

Ground core pins for holes and internal molded features

Core Pins

Core pins for holes, bosses and internal features. Diameter, concentricity, working length, hardness and surface condition are set by the application you describe.

Custom ejector related mold components made to drawing

Ejector Related Components

Special ejector parts and non standard components used inside the ejection system, made to your drawing when the catalogue item does not fit the tool.

Replaceable wear components for sliding and contact areas in a mold

Wear Components

Replaceable parts for areas that see repeated sliding and contact. Material, hardness and fit are chosen against the component drawing and the way the tool actually runs.

Engineer reviewing a 3D model of a custom injection mold component

Custom Mold Components

If the part does not sit in any standard category, send the drawing or 3D model. We review geometry, steel, tolerance, heat treatment and surface requirements before anything is cut.

03New And Replacement

New Mold Components Or Replacement Parts

Whether the part is for a mold you are building or a tool already in production, the manufacturing reference has to be clear before machining starts. What we need from you is different in each case.

Path A

Components For New Molds

For a new tooling project, manufacturing starts from your approved component drawing and 3D model. Before production we go through everything that defines the finished part.

What We Review First

Component geometry and datums
Critical dimensions and tolerances
Mold steel specification
Heat treatment and hardness
Mating and fitting dimensions
Forming surfaces
EDM or grinding requirements
Polishing and surface finish

Machining, heat treatment, finishing and inspection then all run against the same confirmed drawing revision, so nothing gets built to an older file.

Path B

Replacement Components

A replacement part has to fit the mold that is already in service. The more references you can send, the less guessing is left in the fit.

Useful References

Original component drawing
Current mold revision
Existing 3D data
Damaged or worn component
Mating pocket or related part
Parting and shutoff surfaces
Cooling or sealing interfaces
Photos and measured dimensions

Worth Checking Before You Copy A Part

The worn part in your hand is not always a safe manufacturing reference. Wear, polishing, an earlier repair or a mold modification may have moved its dimensions away from the original design, so we compare it against the drawing and the mating features before we cut a new one.

NoteReplacement Geometry

Do Not Copy Wear Into The New Part

If the component has already been repaired, polished or worn in production, copying every measured dimension can build the same problem straight back into your mold.

Where it matters, we look at the drawing, the current mold condition and the mating dimensions together before the replacement geometry is confirmed with you.

Chat With Kim
04Fit And Mating

The Component Must Fit The Mold, Not Just The Drawing

Your components work as part of an assembled tool. A dimension can sit inside tolerance and the part can still give you trouble if the relationship with the pocket, parting surface, shutoff area or mating component is wrong. On critical parts we review the dimensions that control how the component fits and functions inside the mold.

Cavity insert located inside a machined mold pocket Shutoff surface contact area on an injection mold insert Parting surface of an injection mold closed on the press Datum face being set up for machining a mold component Mating dimensions of a mold insert measured before assembly
Insert To Pocket Fit
01

Insert To Pocket Fit

Core and cavity inserts have to locate correctly inside the machined pocket, with enough positioning and support and without excess clearance or interference.

Pocket dimensions, insert dimensions and the datum system get reviewed together, not as three independent features.

02

Shutoff Surfaces

Shutoff surfaces need controlled contact with the mating mold feature. Wrong height, angle or local geometry affects sealing and can show up later as flash or early wear.

We machine and inspect these against the defined mating relationship instead of treating them as ordinary outside geometry.

03

Parting Line Match

Replacement cores, cavities and inserts often form part of the parting surface. Their height and surrounding geometry have to match your existing mold so the parting line closes as designed.

This matters most when the tool has already been polished, repaired or modified in earlier production.

04

Datum Relationships

The datum used for machining and inspection decides how the critical features sit relative to each other. On new components we follow the approved drawing datum system.

On replacement components the current mold condition may also need to be taken into account before the manufacturing reference is fixed.

05

Mating Dimensions

Some dimensions matter because they control the relationship between two components, not the size of one part on its own.

Insert to pocket dimensions
Shutoff contact positions
Parting surface height
Locating steps and shoulders
Mating faces
Assembly clearances
1 / 5
NoteTolerance Strategy

Accuracy Where The Mold Needs It

Not every surface needs the same tolerance, and tightening all of them only adds cost to your part.

Critical fits and mating features get tighter control where the mold function calls for it, while non critical areas are held to the tolerance your drawing already specifies.

05Forming Surfaces

Forming Surfaces Define The Molded Part

The forming surface of a core, cavity or insert is what actually creates the geometry and surface condition of your molded part, so it gets different attention from a mounting or clearance face. Geometry, draft, small features, EDM condition and final finish are all controlled against your approved mold design.

01

Product Geometry

Critical contours, cavities, cores and local features have to match your 3D model and drawing definition, not an approximation of them.

On complex surfaces, machining and inspection run off the same datum and model reference, so the finished geometry stays consistent with the approved design.

3D Model Driven Single Datum
02

Draft Surfaces

Draft controls both the molded geometry and how cleanly the part releases from your tool.

Direction and angle are held through CNC machining, EDM and polishing. Heavy manual finishing is where draft and edge relationships usually get lost, so those surfaces stay controlled.

Angle Held Release Checked
03

Ribs, Bosses And Deep Features

Narrow ribs, deep cavities, small bosses and other restricted areas usually need CNC and EDM working together.

Depth, wall condition, corner geometry and the transition into the surrounding surface are all treated as part of the feature, not as leftovers.

CNC Plus EDM Corner Control
04

Sharp Details And Small Features

Fine slots, small radii and narrow shutoff details are often hard to hold with standard milling alone.

The process gets selected around the geometry instead of pushing every area through the same machining method to keep the route simple.

Process By Feature Small Radii
05

EDM Areas

EDM comes in where milling access is limited or the mold feature is deep and complex.

Electrode geometry, EDM depth and the remaining surface condition follow the specified requirement, which matters most when the area will be polished or textured later.

Electrode Design Surface Condition
06

Cosmetic Surfaces

Visible areas of your part need tighter control on the matching mold surface. Machining marks, EDM texture, polishing direction and local transitions all show up in the plastic.

If a surface needs polishing, mirror finish or later texturing, tell us before final machining so the route is planned for it.

Polish Ready Texture Ready
06Slides And Lifters

Moving Components Must Fit And Move Correctly

Slides and lifters are not just precision machined parts. They have to run the required stroke, close against the right surfaces and return without interference inside your mold, so geometry, fit and contact relationships get controlled together.

Slider component sliding surface after precision grinding
01

Sliding Fit

Sliding surfaces need enough clearance to move reliably without leaving you with play in the tool.

The fit follows your mold design, working condition and lubrication arrangement, rather than one standard clearance applied to every slider we make.

Controlled byMold design and duty
ReferenceApproved drawing fit
Lifter component with machined working angle for undercut release
02

Angle And Travel

Lifter angles, slider movement and working stroke decide whether the undercut releases the way your design intended.

Critical angles, travel related geometry and stop positions come straight from the approved mold data, so the component follows the movement path it was drawn for.

Built fromApproved mold data
Held featuresAngle, stroke, stops
Shutoff contact area machined on a slider face
03

Shutoff Contact

Plenty of sliders and lifters also carry shutoff surfaces that have to close against the mating mold feature in the right position and geometry.

Poor contact here is what later shows up as flash, local wear or molded features that are not consistent from shot to shot.

Checked againstMating mold feature
Failure it preventsFlash and local wear
Hardened wear surfaces on moving mold components
04

Wear And Contact Surfaces

Sliding and contact areas take repeated movement on every cycle your mold runs.

Steel, hardness, surface condition and mating geometry are specified for the working area, so wear is controlled where the contact actually happens.

Specified perWorking area
Variables setSteel, hardness, finish
Mold components checked for clearance along the movement path
05

Clearance Around Moving Features

A moving component may pass close to inserts, cores, ejector features or surrounding mold steel on its way through the stroke.

Clearance gets checked across the complete movement path, not only in the fully open and fully closed positions where most drawings show it.

Checked overFull movement path
AgainstInserts, cores, ejectors
NoteMoving Components

Motion Depends On More Than One Dimension

On slides and lifters, every dimension sitting inside tolerance is not the result you are actually paying for.

The component still has to fit the mating structure, follow the movement your design calls for and close against the correct surfaces once the tool is running.

Chat With Kim
07Steel And Heat Treatment

Steel And Hardness Should Match The Mold Application

Steel is chosen around how the component works inside your mold, the resin you are running, the surface finish you need and the condition the tool operates in. On custom parts we manufacture to the grade, heat treatment and hardness your drawing or specification defines.

What Drives The Steel Decision

Surface Finish Requirements

Cores, cavities and inserts that form a visible surface need steel that polishes the way you expect it to.

If the part calls for mirror polishing, fine polishing or texturing later, the steel condition and heat treatment have to support that result. Deciding it after machining is where finish problems usually start.

Applies toVisible forming surfaces
Decided atQuotation stage
Tell usPolish or texture spec

Wear Conditions

Sliders, lifters, core pins and anything else that moves or meets abrasive compound needs more wear resistance than a static insert does.

That requirement belongs to the working surface. Pushing hardness up across the whole component without looking at function usually costs you toughness somewhere else.

Applies toSliding and contact areas
Set byWorking surface, not whole part
Tell usCycle count and compound

Corrosion Resistance

Some tools sit in moisture, corrosive molding conditions or resins that attack the steel over a long run.

Where that applies, grade and heat treatment are specified for it, particularly on forming surfaces, around cooling areas and on tooling you expect to keep running for years.

Applies toForming and cooling areas
Matters forLong running tooling
Tell usResin and shop conditions

Strength And Dimensional Stability

Hardness on its own does not tell you whether a component is suitable for the job.

The material and heat treatment also have to give enough strength and dimensional stability for the geometry, which is what decides the outcome on precision inserts, long core pins, thin sections and anything that gets ground or fitted after treatment.

Critical onLong pins and thin sections
RiskMovement after treatment
Handled byFinishing allowance

Molded Material

What you are molding changes what the component needs. Glass filled and abrasive resins push wear on forming and moving surfaces much faster than unfilled material.

Other jobs shift the priority to corrosion resistance or surface quality instead, so the steel specification is looked at together with the resin, the mold function and the production condition you expect.

Abrasive resinsWear resistance first
Cosmetic partsPolishing quality first
Tell usResin, filler, output

Heat Treatment Sits Inside The Machining Sequence

When heat treatment is required, it has to be coordinated with the machining order, because critical dimensions are only controlled after the processes that can still move them. Depending on the component and your drawing, the route runs like this.

01

Rough Machining

Bulk material removed before the part goes to treatment

02

Heat Treatment

Processed to the hardness your specification defines

03

Finishing Allowance

Stock left on critical faces for post treatment work

04

Final Grinding Or EDM

Critical geometry cut after the part is hardened

05

Hardness Verification

Checked against the specified range before release

06

Final Inspection

Dimensions confirmed after every process that moves them

Chat With Kim
08Machining And Finishing

Machining Each Feature With The Right Process

One mold component can carry complex 3D surfaces, deep cavities, precision slots, fitting faces and hardened dimensions on the same part. The process is picked around the feature being produced, the tolerance it needs and what that surface has to do in your mold.

CNC milling the main geometry of an injection mold insert
01 / 05

CNC Milling

Milling handles the main component geometry, pockets, profiles, 3D surfaces and the mold features a cutter can reach cleanly.

Allowance and process order are planned around what comes next, so a part heading for heat treatment, EDM, grinding or final finishing is left with the stock those steps need.

EDM sinking a deep cavity feature in a mold component
02 / 05

EDM

EDM takes the features that milling either cannot reach or cannot hold efficiently, including deep cavities, narrow ribs, internal corners and complex forming details.

Electrode geometry and EDM depth are controlled against your approved 3D model and drawing, which also decides the surface condition left for polishing or texturing later.

Wire EDM cutting a precision profile in a hardened mold insert
03 / 05

Wire EDM

Wire EDM suits precision profiles, slots, openings and other through features where the geometry has to be accurate rather than approximately right.

It earns its place when profile accuracy, straightness or control of a narrow feature is what decides whether the finished component works in your tool.

Surface grinding a hardened mold component to final thickness
04 / 05

Precision Grinding

Grinding comes in where flatness, thickness, squareness and fitting dimensions need tighter control than milling gives you.

Insert fitting surfaces
Reference faces
Sliding surfaces
Thickness dimensions
Precision shoulders

Where it sits in the route depends on the material condition and the final dimension you need held.

Final fitting and inspection of a finished mold component
05 / 05

Final Machining

Critical dimensions are finished after the processes most likely to move them, not before.

Depending on the component that last stage may be precision milling, EDM, grinding, fitting or whatever finishing your drawing specifies, and inspection follows it rather than sitting somewhere in the middle.

NoteProcess Route

The Process Follows The Feature

A complex mold component is rarely finished on one machine. A typical route through our shop looks like this.

Rough Machining Heat Treatment CNC And EDM Grinding Final Dimensions Inspection

The exact sequence comes from your component geometry, steel condition, tolerance and surface requirements, so it is confirmed per part rather than fixed in advance.

Chat With Kim
09Cooling And Sealing

Cooling And Sealing Features Must Match The Mold Design

Cooling holes, water channels and sealing features are part of how your mold works, not secondary machining details. Position, depth, intersection and sealing geometry follow the approved drawing so the component connects correctly with the cooling system and sealing arrangement already in the tool.

Cooling Hole Position

Cooling holes are located to the mold geometry your drawing defines, not to whatever is convenient on the machine.

Wrong position or depth changes the cooling layout you designed, and usually shows up as a problem when the component meets the surrounding plates and fittings during assembly.

ControlledPosition and depth
Checked withSurrounding plates

Channel Intersections

Cross drilled channels need their depth and intersection controlled, because that is where a water path either forms correctly or opens somewhere it should not.

Hole direction, drilling depth and connection points are verified against the drawing before the part leaves the machine.

VerifiedDirection and depth
PreventsUnintended openings

O Ring Grooves

Sealing grooves need the right diameter, width, depth and relationship to the mating surface to actually hold a seal.

They are machined to the specified seal design rather than cut as general grooves that happen to be close to the drawing size.

Held featuresWidth, depth, diameter
Built toSpecified seal design

Sealing Surfaces

The surface around a cooling connection or O ring groove is part of the sealing system, even though it carries no feature of its own.

Flatness, surface condition and local geometry are held so the contact with the mating component is the one your design assumed.

ControlledFlatness and finish
Contact withMating mold component

Cooling Interfaces

Threaded ports, fittings, plugs and connecting holes have to line up with the mold structure around them.

Connection type, thread specification, location and depth get confirmed with you before machining, which matters most on a replacement part that has to match a tool already running.

Confirmed firstThread and connection
Critical forReplacement components
NoteCooling Circuit

Check The Complete Cooling Path

A single hole can measure correctly while the complete circuit is still wrong.

On components with internal cooling, hole position, depth, intersections, sealing areas and connection points get reviewed together before final inspection, not one feature at a time.

If you need pressure or leakage testing, define it in the drawing or project specification before production so it is priced and planned into the route.

Chat With Kim
10Surface Finish

Surface Finish Should Follow The Function Of Each Area

The surface condition of a mold component shows up in molded part appearance, fit, movement and sealing. So the requirement gets defined area by area, according to what that surface does, instead of running one finish across the whole part and paying for it everywhere.

Machined surface condition on a mold component after milling 01

Machined Finish

Where It AppliesNon cosmetic, non contact areas that can stay in the machined condition your drawing specifies.

Still ControlledTool marks, machining direction and final roughness follow the drawing wherever a surface requirement is called out.

EDM surface condition inside a mold cavity feature 02

EDM Finish

Where It AppliesEDM areas that either stay as machined or move on to further finishing, depending on what the surface does.

Confirm FirstOn forming areas the EDM condition is agreed before polishing or texturing, so stock removal later does not move the geometry you designed.

Ground fitting face on a precision mold insert 03

Ground Surfaces

Where It AppliesAreas where flatness, thickness, squareness or controlled contact decide whether the part fits your tool.

Typical AreasFitting faces, sliding areas, locating surfaces and other precision interfaces that carry a real mating relationship.

Polishing a forming surface on an injection mold cavity 04

Polished Surfaces

Where It AppliesForming surfaces that need polishing to give you the molded appearance or the release condition the part depends on.

Scope ItPolish is called out only on the areas that need it, so critical edges, dimensions and transitions are not softened for no reason.

Mirror finished mold cavity surface for high gloss parts 05

Mirror And Cosmetic Finishes

Where It AppliesHigh gloss molded surfaces, which need a finer mold finish than general functional areas.

What Supports ItSteel condition, earlier machining, EDM quality and polishing allowance all have to line up. Mirror finish is a route decision, not a last step.

Mold surface prepared before texture treatment 06

Texture Preparation

Where It AppliesForming areas heading for texture treatment, where the incoming surface condition decides the texture result.

Prepared To SpecThe area is finished to your texture specification without removing critical geometry or changing local draft and edge relationships.

NoteFinish Scope

One Component Can Require Several Finishes

A single core, cavity or insert often carries all of these at once.

Polished Forming Surfaces Ground Fitting Surfaces EDM Areas Sliding Contact Surfaces Machined Clearance Areas

Mark them separately on the drawing or in the approved manufacturing information, and the finish gets priced and produced for each area instead of averaged across the part.

Chat With Kim
11Replacement Components

Replacement Parts Must Match The Existing Mold

A damaged or worn component should not be copied before someone checks the mold it has to go back into. Before we manufacture a replacement, we go through the available drawing, the current mold revision and the critical mating features to fix the right manufacturing reference.

Worn mold insert measured against the original drawing before a replacement is made

Reference

Drawing First

Checked

Mating Features

Quote

24 h

01

Check The Current Revision

If the mold has been modified since it was built, the latest approved revision is the one we work from wherever it is available. An old file is the most common reason a new part does not drop in.

02

Review The Existing Component

The damaged part still tells us a lot, but wear, polishing and earlier repair may have moved its dimensions away from the design. We read it as evidence, not as the drawing.

03

Confirm Critical Mating Features

Pocket fit, parting surfaces, shutoff areas, locating features and the related interfaces are checked against the current condition of your mold rather than the original intent alone.

04

Match Surface And Functional Features

Cooling connections, sealing areas, polished surfaces and other functional details are built to what the tool in service actually needs, so the part works the day it goes in.

Replace The Component, Not The Wear

The target is a part that fits and functions in your existing mold, not a faithful copy of every dimension measured off the worn one.

Chat With Kim
12Inspection

Inspection Focused On Critical Mold Features

Checks come from your approved drawing and from what each component has to do inside the mold. Critical dimensions, mating features, forming geometry and the specified material condition are all verified before the part is released to you.

Cavity profile measured against the approved 3D model
01 / 06

Forming Profiles

Core, cavity and insert profiles are checked against your drawing or 3D model wherever dimensional verification is required.

Complex geometry gets measured with equipment suited to the feature and the tolerance, rather than forcing every profile through the same check.

ReferenceDrawing and 3D model
MethodSet by feature and tolerance
Mating dimensions of a mold insert checked before release
02 / 06

Fit And Mating Dimensions

The dimensions that decide how the component sits in your mold get the most attention, because these are what you feel during assembly.

Insert and pocket dimensions
Locating steps and shoulders
Mating faces
Parting surface heights
Shutoff related dimensions
Ground reference face checked for flatness on a surface plate
03 / 06

Flatness And Squareness

Reference faces, fitting surfaces and ground areas are checked where flatness, parallelism or squareness changes how the part assembles.

These are the features that pass a caliper check and still cost you time on the bench, so they are verified in the condition you receive them.

Applies toReference and ground faces
Checked forFlatness and squareness
Slider and lifter features inspected against the approved drawing
04 / 06

Slides And Lifters

Critical slider and lifter features are checked on the dimensions that control fit, angle, contact surfaces and mating geometry.

Inspection follows the approved drawing instead of treating a moving component as an ordinary machined part with a few sizes to confirm.

FocusFit, angle, contact
ReferenceApproved drawing
Hardness testing a heat treated mold component
05 / 06

Hardness

Where your specification calls out hardness, the finished component is tested according to the material and heat treatment requirement.

The verified result has to sit inside the approved range before the part moves on, and it can be recorded on the inspection report you receive.

Tested atFinished condition
Recorded onInspection report
Cooling holes and sealing grooves verified on a finished mold component
06 / 06

Cooling And Sealing Features

Cooling hole locations, groove dimensions, connection features and sealing geometry are inspected wherever they are defined as critical.

If pressure or leakage testing belongs in the acceptance scope, tell us at quotation so it is planned into the route rather than added at the end.

CheckedHoles, grooves, connections
OptionalPressure or leak testing
NoteInspection Scope

Inspection Follows The Drawing

Not every dimension needs the same inspection method, and measuring everything the same way just moves cost around without protecting your tool.

Critical and functional features are identified from your approved drawing, so the effort sits on the dimensions that decide fit, movement, forming and assembly.

Chat With Kim
13Repeat Spare Parts

Repeat Spare Parts From Approved Component Data

Molds need the same inserts, core pins, lifters, sliders and wear components again through maintenance and long production runs. Once a component is approved, the manufacturing information stays tied to that part and revision, so the next set comes off the same reference instead of a fresh interpretation.

Approved mold components prepared as repeat spare parts

Reorder From

Stored Records

Revision

Controlled

Quote

24 h

01

Controlled Drawing Revision

Repeat parts are built from the approved revision, not an older file or an unverified copy that has been sitting on the shop floor.

02

Material And Heat Treatment

Steel grade, heat treatment and hardness stay in the component record, so the next batch follows the same material specification you already accepted.

03

Dimensions And Surface Requirements

Critical dimensions, fitting features, polishing requirements and the approved surface conditions are kept with the component specification.

04

Inspection Requirements

The same critical features are checked against the inspection requirements already established, so a repeat order is verified the way the first one was.

Chat With Kim
NoteSpare Orders

Reduce Rework On Future Spare Orders

When the approved component data stays controlled, your next spare part is reproduced from that reference instead of rebuilding the whole manufacturing basis from the beginning each time you need one.

14Factory Manufacturing

Inside Our Injection Mold Components Factory

Machining, EDM, grinding, finishing and inspection all run in house, against your approved drawings and project requirements.

From a single insert or core pin to complex sliders, lifters, cores and cavity components, every part follows a defined manufacturing route before it reaches final inspection and release to you.

CNC machining floor producing mold components
EDM machines running mold cavity features
Precision grinding station for hardened components
Wire EDM cutting precision profiles
Inspection bench with measuring equipment
Finished mold components packed for export

Want to see a specific process before you place the order? We send machining photos, in process images and inspection records on request.

Chat With Kim
15Case Studies

Injection Mold Component Case Studies

Different components fail, fit and function in different ways. These projects show how drawing requirements, existing mold conditions, critical interfaces and inspection points get handled on both new builds and replacement work.

Replacement cavity insert machined for an existing production mold
Reviewed Drawing, current part condition, mating dimensions
Focus Forming geometry, fit, shutoff, surface condition
Inspection Profile and mating dimensions against the reference
Replacement

Replacement Cavity Insert

A production mold needed a new insert that would sit in the existing pocket, meet the parting surface and hold the defined forming geometry.

Replacement slider component made after wear in production
Reviewed Revision, wear condition, contact surfaces
Focus Sliding surfaces, locating geometry, shutoff areas
Inspection Fit, angle and mating dimensions before release
Replacement

Replacement Slider

A slider had worn in production. The new one had to keep the specified sliding fit, shutoff geometry and its relationship with the mating mold features.

Custom lifter component manufactured from supplied mold data
Reviewed Supplied mold data and specified angle
Focus Angle, working profile, fit and contact areas
Inspection Geometry and dimensional relationships to drawing
Custom Build

Custom Lifter Component

Built from the customer's mold data. It had to follow the specified angle and geometry while holding the required contact and fitting surfaces.

Precision core pins produced for mold maintenance stock
Reviewed Diameter, working length, locating features
Focus Straightness, concentricity, working surfaces
Inspection Diameters, lengths and specified hardness
Spare Parts

Precision Core Pins

Core pins for maintenance and spare part replacement, with diameter, working length, locating features and material condition all held to the drawing.

New core and cavity inserts machined for a new mold build
Reviewed Approved 2D and 3D data
Focus Complex profiles, EDM areas, fit, surface spec
Inspection Forming and assembly dimensions to the design
New Mold

New Core And Cavity Inserts

Inserts for a new mold build, producing the forming geometry, fitting surfaces and specified finish from the approved 2D and 3D data.

Repeat spare mold components produced from approved records
Reviewed Stored revision, steel spec, inspection record
Focus Repeatability against approved component data
Inspection Same critical features as the first approved run
Repeat Order

Repeat Spare Components

Previously approved components made again for maintenance stock, keeping the same revision, steel specification, critical dimensions and inspection requirements.

Chat With Kim
16RFQ Requirements

What To Send For A Mold Component Quote

The clearer the manufacturing information, the better we can review the component before pricing it. For most parts, send the latest drawing or model together with the material, tolerance and surface requirements that define the finished component.

Send the newest drawing you have, showing the dimensions and requirements needed to actually make the part.

Critical dimensions and tolerances
Datums
Steel grade
Hardness
Surface finish
Special notes

A model earns its keep on cores, cavities, inserts, sliders and anything else with complex forming geometry.

Check that the 3D file and the 2D drawing point at the same revision before you send them. A mismatch there is one of the most common reasons a quote has to go back for clarification.

Tell us which component you need, so we read the drawing the way the mold uses the part.

Core
Cavity insert
Mold insert
Slider
Lifter
Core pin
Other custom component

Confirm whether the component is for a new mold or one already in service.

On replacement work, the current mold condition and the mating features often matter more than the damaged component in your hand.

Mold steel
Heat treatment
Hardness
EDM condition
Grinding requirement
Polishing
Texture preparation
Other surface requirements

If something is still open, mark it as open. That is far better for you than leaving the manufacturing reference to interpretation.

Include the quantity you need and say whether it is initial manufacturing, maintenance stock or repeat spare part supply. That changes how we plan the route and how we price a follow up order.

Original component drawing
Current mold revision
Existing 3D data
Photos of the damaged part
Relevant mating dimensions
Pocket or surrounding mold info
Parting or shutoff details
Cooling or sealing interfaces
SendYour Package

The Minimum That Gets You A Real Quote

Everything else helps, but with these four we can review the component and come back to you properly.

Drawing or modelLatest revision
Steel and hardnessOr mark as open
Component typeFunction in the mold
QuantityAnd purpose

File Formats We Read

STEP IGES DWG DXF PDF Photos

Response Time

Quotes come back within 24 hours on business days, with any open point named rather than assumed.

Chat With Kim
NoteManufacturing Reference

The Existing Mold Is Part Of The Reference

On replacement components, the worn or damaged part is rarely enough on its own to build from.

What the existing mold tells us about dimensions and interfaces is often what confirms the ones your new component actually has to match.

17FAQ

Frequently Asked Questions

The questions buyers usually raise before sending a mold component drawing, answered the way we would answer them on a call.

01

Can you manufacture replacement components for an existing injection mold?

Yes. Replacement cores, cavity inserts, sliders, lifters, core pins and other custom components can be made from your available drawings, 3D data and existing mold information.

On replacement work the damaged part is not treated as the only reference. Wear, polishing, an earlier repair or a mold modification may have moved its dimensions, so critical mating features are reviewed against the mold before the manufacturing reference is confirmed with you.

02

What if the original component drawing is no longer available?

A missing drawing does not stop the job, but it does mean we need more from you.

Useful references include the existing component, the mating pocket, related mold parts, 3D mold data, previous revisions, measurement records and clear photos. We review what you have before telling you whether the component can be reconstructed accurately enough to manufacture.

03

Should I provide both a 2D drawing and a 3D model?

On components with complex forming geometry, both is better.

The 3D model carries the surfaces and geometry, while the 2D drawing usually carries tolerances, datums, steel, hardness, surface finish and the rest of the manufacturing requirements. Both files should represent the same approved revision.

04

How do you control insert to pocket fit?

Fit comes from the dimensions and datum relationships in your approved drawing.

On critical inserts, fitting dimensions, locating steps, shoulders and mating surfaces are handled as functional features rather than ordinary outside dimensions.

For a replacement, we may also need pocket or mating information if the mold has been repaired or modified since it was built.

05

What needs to be controlled on sliders and lifters?

More than individual dimensional tolerances.

The critical features are usually sliding fit, working angle, shutoff geometry, contact surfaces, locating features, travel related geometry and clearance to the surrounding components. Which ones matter most depends on how the part functions in your specific mold.

06

Can you work with different mold steels and hardness requirements?

Yes. Components are made to the steel grade, heat treatment and hardness your approved drawing specifies.

Selection should account for component function, molded resin, wear condition, corrosion resistance and the surface finish you need. We do not treat higher hardness as automatically better for every component, because it usually costs toughness somewhere.

07

Can forming surfaces be supplied polished or mirror finished?

Where it is specified, forming surfaces can be finished to the required polishing condition within our confirmed capability.

Mark the finish on the relevant surfaces, since one component often carries polished forming areas, ground fitting faces, EDM surfaces and machined clearance areas at the same time.

Mirror and cosmetic finishes should be defined before final processing, so the steel condition and the earlier machining support the result you want.

08

How are dimensions controlled after heat treatment?

The sequence is planned around the processes that can still move the geometry.

Depending on the component that means rough machining first, a controlled allowance, heat treatment, then grinding, EDM or finish machining. Critical dimensions are verified after the operations that establish the finished geometry, not before them.

09

Can you machine cooling holes, O ring grooves and sealing features?

Yes, when the features are clearly defined in the drawing or model.

Hole position, drilling depth, channel intersections, O ring groove geometry, threaded connections and sealing surfaces all follow the specified mold design. If you need pressure or leakage testing, define it as part of the project requirements so it is planned and priced in.

10

How do you handle repeat spare parts for the same mold?

Repeat components come from controlled manufacturing information tied to the correct part and revision.

That record holds the approved drawing revision, steel grade, hardness, critical dimensions, surface requirements and inspection criteria. Reusing the same confirmed reference is what keeps your next spare order off outdated mold data.

18Send Mold Requirements

Send Your Drawing And Get A Quote In 24 Hours

Attach the component drawing or 3D model, tell us the steel, hardness and quantity, and you get a quote with our review notes back within 24 hours on business days.

Tell Us About The Component

Four fields. If you have the drawing ready, mention the file format and we send you an upload link with the reply.

Please enter your name.

Please enter a valid email address.

Please tell us about the component.

Your drawings and project details stay between you and our engineering team. We reply within 24 hours on business days.

Chat With Kim
